After upgrading from MIUIv4 to v6, I've discovered that the new version comes with a bootloader that
- reflashes the recovery partition each time it's run with the stock recovery, which makes it impossible to use a custom recovery in order to install unsigned .zip patches,
- doesn't support download mode, which makes it impossible to connect the phone to a computer as a block device and repartition it.
Since resolving this wasn't completely trivial (to me) and required a bit of research, I took some notes for future reference. I decided to compile these notes into a guide in hope that someone will find it useful. Keep in mind that while I do have technical background, I'm not intimately acquainted with the inner workings of Android and there was some trial and error involved. As a result, some steps may be too heavy-handed or even unnecessary and I therefore encourage comments.
PrerequisitesThe guide presumes one has the
adb,
fastboot and
parted binaries installed on a (presumably un*x) box, which enables access to block devices via the filesystem. For most users, that means a linux box.
List of files- xiaomi.eu_multi_aries_5.8.6_v6-5.0.zip The MIUI6 v5.8.6 Czech ROM. Downloaded from [5].
- emms_appsboot.mbm A fixed bootloader for MIUI6 v5.8.6, which allows for the installation of recoveries other than the
- built-in one (see Reinstalling the recovery). Downloaded from [2].
- recovery-clockwork-6.0.5.0-aries-20140718.img A recovery image of a custom version of the clockworkmod. Extracted from the archive downloaded from [1].
- cm-11-20150802-NIGHTLY-aries.zip An alternative ROM (Cyanogenmod 11). downloaded from [6].
Download modeBooting into download mode appears to be disabled in MIUI6 v5.8.6. You will therefore need to boot into a custom recovery (see Booting into a custom recovery mode) and flash an alternative ROM
(it would likely suffice to flash only certain partitions?):
Code:
$ adb push cm-11-20150802-NIGHTLY-aries.zip /storage/sdcard0
To boot into the download mode with an alternative ROM, consult [
3] or run
adb reboot dload against the phone in the system or in the recovery mode.
Repartitioning the internal flash memoryIn my experience, the default size of the
/system partition is insufficient to accommodate all the system applications along with the ever-growing Google Apps. The original inspiration came from [
4]. To adjust the partition sizes, I used the
parted command-line tool, since it comes with full support for GPT partitions and labels.
Gparted used, but (as of v0.19.0-2) appeared to be much slower compared to
parted and didn't seem to fully support GPT partition labels. Keep in mind that, unlike
gparted,
parted applies the changes to the block device immediately. Proceed with caution.
Before starting, it's best to backup the current partition table for a reference:
Code:
# gparted /dev/sdc
GNU Parted 3.2
Using /dev/sdc
Welcome to GNU Parted! Type 'help' to view a list of commands.
(parted) unit MiB
(parted) print
Number Start End Size File system Name Flags
1 0,02MiB 85,0MiB 85,0MiB fat16 modem msftdata
2 85,0MiB 170MiB 85,0MiB fat16 modem1 msftdata
3 170MiB 171MiB 0,50MiB sbl1
4 171MiB 171MiB 0,50MiB sbl2
5 171MiB 172MiB 1,00MiB sbl3
6 172MiB 173MiB 1,00MiB rpm
7 173MiB 174MiB 1,00MiB tz
8 174MiB 175MiB 0,50MiB DDR
9 175MiB 179MiB 4,00MiB aboot
10 179MiB 180MiB 1,00MiB misc
11 180MiB 182MiB 2,85MiB logo
12 182MiB 183MiB 0,76MiB m9kefs1
13 183MiB 184MiB 0,76MiB m9kefs2
14 184MiB 184MiB 0,00MiB m9kefsc
15 184MiB 192MiB 8,11MiB bk1
16 192MiB 193MiB 0,76MiB m9kefs3
17 193MiB 256MiB 63,2MiB bk2
18 256MiB 271MiB 15,0MiB boot
19 271MiB 286MiB 15,0MiB boot1
20 286MiB 301MiB 15,0MiB recovery
21 301MiB 312MiB 11,0MiB bk3
22 312MiB 320MiB 8,00MiB ext4 persist
23 320MiB 832MiB 512MiB ext4 system
24 832MiB 1344MiB 512MiB ext2 system1
25 1344MiB 1728MiB 384MiB ext4 cache
26 1728MiB 5312MiB 3584MiB ext4 userdata
27 5312MiB 29820MiB 24509MiB ext4 storage
Mind that
/dev/sdc refers to the block device of my phone and will differ on your system depending on the amount of other block devices connected and the type of your system. It's also best to backup either the entire block device (
/dev/sdc) or at last the specific partitions you are going to be messing with (
/dev/sdcXY) this is doubly important for partitions <= 22, the correct content of which may be difficult to retrieve when damaged. Labels
(most likely) aren't important, the partition numbers are, so make sure you keep their order when fiddling with them.
After finishing, reconnect the phone to make the kernel recognize the new partition structure and create the filesystem (
mkfs.ext4) for any partitions you have created. The following example makes the system and system1 partitions 1GiB each and the userdata partition 4GiB at the expense of the storage partition:
Code:
# parted /dev/sdc
GNU Parted 3.2
Using /dev/sdc
Welcome to GNU Parted! Type 'help' to view a list of commands.
(parted) rm 23
(parted) rm 24
(parted) rm 25
(parted) rm 26
(parted) rm 27
(parted) mkpart physical ext4 320MiB 1344MiB
(parted) mkpart physical ext4 1344MiB 2368MiB
(parted) mkpart physical ext4 2368MiB 2752MiB
(parted) mkpart physical ext4 2752MiB 6848MiB
(parted) mkpart physical ext4 6848MiB 29819MiB
(parted) name 23 system
(parted) name 24 system1
(parted) name 25 cache
(parted) name 26 userdata
(parted) name 27 storage
(parted) quit
# sync
And then, after reattaching the phone to the computer:
Code:
# for i in /dev/sdc2[34567]; do mkfs.ext4 $i; done
# sync
Recovery modeFor booting into recovery, consult [
3].
Booting into a custom recoveryUse the process described at [
2], with steps 7-8 interchanged with 9-10. I used the
emms_appsboot.mbm and
recovery-clockwork-6.0.5.0-aries-20140718.img files (see
List of files) from the fastboot mode as follows:
Code:
$ fastboot flash recovery recovery-clockwork-6.0.5.0-aries-20140718.img
$ fastboot flash aboot emmc_appsboot.mbn
$ fastboot boot recovery-clockwork-6.0.5.0-aries-20140718.img
If the phone gets stuck at booting during the last step, restart the phone and try again.
You should now be in the custom recovery. For me, this only lasted until a reboot. Then, the recovery was replaced with the stock one and it became impossible to boot into the system, effectively softbricking the phone. To fix this, flash the stock
emmc_appsboot.mbm bootloader image extracted from the .zip of the MIUI ROM you are using and flash it from the fastboot mode:
Code:
$ fastboot flash aboot ./the/original/emmc_appsboot.mbn
$ fastboot continue
Booting into fastboot modeTo boot into the fastboot mode, either:
- Reboot the phone while holding the volume down button.
- Run adb reboot bootloader against the phone in the system or in the recovery mode.
